Features
1. Input notification for reducting misplugging risks
2. Low battery indication, over-range display
3. Data hold; diode/continuity buzzer
4. Dwell: Measure the dwell angle of points-type ignition systems
5. RPM: Measure engine spindle rotation per minute
| Specifications | Range | Best Accuracy |
| Model | UT105 | |
| DC Voltage (V) | 200mV/2V/20V/200V/1000V | ±(0.5%+5) |
| AC Voltage (V) | 2V/20V/200V/750V | ±(0.8%+5) |
| DC Current (A) | 200mA/10A | ±(0.8%+5) |
| Resistance (Ω) | 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ | ±(0.8%+5) |
| Features | ||
| Display Count | 2000 | |
| Manual Range | √ | |
| Battery Test | 12V | |
| Duty Cycle | 1%-90% | |
| Diode | √ | |
| Continuity Buzzer | √ | |
| Low Battery Indication | √ | |
| Data Hold | √ | |
| Input Protection | √ | |
| Input Impedance for DCV | Around 10MΩ | √ |
| Dwell | 4CYL/6CYL/8CYL | ±(3%+5) |
| Tach | 4CYL/6CYL/8CYL | ±(3%+5) |
| General Characteristics | ||
| Power | 9V Battery (6F22) | |
| LCD Size | 60mm X 54 mm | |
| Product Color | Red and grey | |
| Product Net Weight | 351g (Including holster) | |
| Product Size | 179mm X 88mm X 39mm | |
| Standard Accessories | Battery, test lead, holster | |
| Standard Individual Packing | Gift box, English manual | |
| Standard Quantity Per Carton | 40pcs | |
| Standard Carton Measurement |
645mm × 450mm × 340mm (0.0987 CBM per standard carton) |
|
| Standard Carton Gross Weight | 24.6kg | |
