Features
1. Display count: 3000
2. Auto SCAN and range identify mode
3. Data hold, auto power off, low battery indication
4. MAX/MIN modes
5. LCD backlight and flashlight
6. Non-contact voltage detection
| Specifications | Range | Best Accuracy | |
| Model | SCAN Mode | AUTO Mode | UT118B |
| DC Voltage (V) | 3V/30V/300V | 3V/30V/300V | ±(1%+3) |
| AC Voltage (V) | 3V/30V/300V | 3V/30V/300V | ±(1%+4) |
| Resistance (Ω) | 300Ω/3kΩ/30kΩ/300kΩ/3MΩ | 300Ω/3kΩ/30kΩ/300kΩ/3MΩ/30MΩ | ±(1%+3) |
| Capacitance (F) | 3nF/30nF/300nF/3μF/30μF/300μF | 3nF/30nF/300nF/3μF/30μF/300μF/3mF | ±(3%+5) |
| Features | |||
| Display Count | 3000 | ||
| Auto Range | √ | ||
| EF Function | √ | ||
| Diode | √ | ||
| Auto Power Off | around 10 minutes | √ | |
| Continuity Buzzer | √ | ||
| Low Battery Indication | √ | ||
| Data Hold | √ | ||
| MAX Mode | √ | ||
| MIN Mode | √ | ||
| LCD Backlight | √ | ||
| Penlight | √ | ||
| Input Impedance for DCV | ≥10MΩ | √ | |
| General Characteristics | |||
| Power | 3V Li-MnO2 Cion cell battery | ||
| LCD Size | 28mm × 14mm | ||
| Product Color | Red and grey | ||
| Product Net Weight | 90g | ||
| Product Size | 20mm × 27mm × 182mm | ||
| Standard Accessories | Battery, test lead | ||
| Standard Individual Packing | Blister, English manual | ||
| Standard Quantity Per Carton | 80pcs | ||
| Standard Carton Measurement | 570mm × 300mm × 415mm (0.071 CBM per export carton) | ||
| Standard Carton Gross Weight | 12.5kg | ||
