UT262 A/C

Features

1. Clamp opening, 1.6~16mm

2. Power on indication

3. Auto power off

4. LED, buzzer indication

Functions	Range	Accuracy
Type		UT262A
Phase Sequence	【Positive Phase】indicated by four phasedetecting lights turn on clockwise and non-continuous beeping sound.	√
Phase Sequence	【Negative phase】indicated by four phase detecting lights turn on anti-clockwise and continuous beeping sound	√
Missing Phase Detection	R-S or S-T light Off	√
Live Power Detection	R-S or S-T light On	√
Circuit Break Detection	R-S or S-T light Off	√
Voltage Detection	R-S or S-T light On	√
AC Voltage Range (V)	70V~600V	√
Frequency Range (Hz)	40Hz~70Hz	√
Features
Clamp Open		Φ1.6~Φ16mm
Display Mode		LED
Power On Indication		√
Buzzer Indication		√
Auto Power Off	Automatically switch off after three minutes	√
General Characteristics
Power	1.5V battery (5#）X 2
Product Color	Red and Grey
Product Weight	180g
Product Size	70mm X 75mm X 30mm
Standard Accessories	Batteries
Standard Individual Packing	Blister, User manual
Standard Quantity Per Carton	20pcs
Standard Carton Measurement	800mm X 300mm X 400mm
Standard Carton Gross Weight	9kg
