Features
1. Single channel, 3-bit digital display, shows voltage and current simultaneously
2. Voltage display resolution: 100mV; current display resolution: 10mA
3. Voltage output: 0~30V consecutive and adjustable voltage
4. Current output: 0~3A
5. Auto voltage and current stabilization conversion, current limiting protection, undamaged for any external usage
| Specifications | UTP3313TFL | UTP3315TFL |
| Output voltage | 0~30V | |
| Output current | 0~3A | 0~5A |
| Load efffect | CV≤1×10-4+2mV, CC≤2×10-4+3mA | |
| Ripple & Noise | ≤0.3mVrms | |
|
Output regulation resolution |
CV: 100mV (typical), CC: 10mA (typical) | |
| Reliability | MTBF(e): ≥2000hrs | |
| Display mode | LED voltage and current dual display | |
| Feature | Auto conversion of constant voltage and current with current limit protection | |
| General characteristics | ||
| Power | Input voltage: 110V AC/220V AC; frequency: 40Hz~60Hz | |
| Product color | White and grey | |
|
Standard accessory |
Power cord | |
| Product net weight | 3kg | 4kg |
| Product size (W×H×D) | 105mm×160mm×240mm | |
