Features
1. NCV
2. Ergonomic and lightweight
3. Auto range, 2~3/s sampling rate
4. True RMS
5. ZERO mode
6. LCD backlight, data hold；
7. Auto power off, low battery indication
| Specifications | Range | Best Accuracy | |
| Model | UT210D | UT210E | |
| AC Current (A) | 20A/200A | ±(2.5%+8) | |
| 2A/20A/100A | ±(2.5%+5) | ||
| DC Current (A) | 20A/200A | ±(2%+3) | |
| 2A/20A/100A | ±(2%+3) | ||
| AC Voltage (V) | 2V/20V/200V/600V | ±(1%+3) | ±(1%+3) |
| DC Voltage (V) | 200mV/2V/20V/200V/600V | ±(0.7%+3) | ±(0.7%+3) |
| Resistance (Ω) | 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ | ±(1%+2) | ±(1%+2) |
| Frequency | 10Hz/100Hz/1kHz/10kHz/60kHz | ±(0.1%+4) | |
| Capacitance (F) | 2nF/20nF/200nF/2μF/20μF/200μF/2mF/20mF | ±(4%+5) | ±(4%+5) |
| Temperature (℃) | -40~1000℃ | ±(1%+3) | |
| Temperature (℉) | -40~1832℉ | ±(1.5%+5) | |
| Features | |||
| Display Count | 2000 | 2000 | |
| Auto Range | √ | √ | |
| Jaw Capacity | 17mm | 17mm | |
| True RMS | √ | √ | |
| Diode | Around 3.0V | √ | √ |
| V.F.C. | √ | ||
| NCV | √ | √ | |
| Auto Power Off | Around 15 minutes | √ | √ |
| Continuity Buzzer | √ | √ | |
| Low Battery Indication | ≤2.5V | √ | √ |
| Data Hold | √ | √ | |
| Zero Mode | √ | √ | |
| LCD Backlight | √ | √ | |
| Input Protection | √ | √ | |
| Input Impedance for DCV | ≥10MΩ | √ | √ |
| General Characteristics | |||
| Power | AAA 1.5V x 2 | ||
| LCD Size | 39.3mm x 26.5mm | ||
| Product Color | Red and grey | ||
| Product Net Weight | 170g | ||
| Product Size | 175mm x 60mm x 33.5mm | ||
| Standard Accessories | UT210D - Batteries, Test Leads, Temperature Probe | ||
| UT210E - Batteries, Test Leads | |||
| Standard Individual Packing | Gift Box, Carrying bag, English Manual | ||
| Standard Quantity Per Carton | 40pcs | ||
| Standard Carton Measurement | 385mm x 345mm x 305mm (0.041 CBM Per Standard Carton) | ||
| Standard Carton Gross Weight | 11kg | ||
