Clamp meter

UT208

Product description: 1000A Digital Clamp Meter
INQUIRY

UT208 is a stable, safe and reliable, low power consumption 3 5/6 AC digital clamp meter, full range overload protection and unique appearance design, which becomes more superior performance of electrical instruments. It is suitable for smelt, manufacturing, petroleum, electric power, chemical industry etc. It’s an ideal tool for the maintenance and repair of the circuit, power equipment.

1. 1000A AC/DC current measurement, 3 times/ssampling rate

2. Zeroing function with relative mode

3. LCD backlight

4. Data hold

5. Auto power off and low battery indication

Specifications	Range	Best Accuracy
Model		UT208
AC Current (A)	66A/1000A	±(2%+8)
DC Current (A)	66A/1000A	±(1.5%+8)
AC Voltage (V)	6.6V/66V/600V	±(1.2%+5)
DC Voltage (V)	6.6V/66V/600V	±(0.8%+1)
Resistance (Ω)	600Ω/6.6kΩ/66kΩ/660kΩ/6.6MΩ/66MΩ	±(1%+2)
Frequency (Hz)	660Hz/6.6kHz/66kHz/660kHz/6.6MHz/66MHz	±(1%+3)
Temperature (°C)	-40°C～1000°C	±(1%+3)
Temperature (°F)	-40°F～1832°F	±(1%+4)
Features
Display Count		6600
Auto Range		√
Jaw Capacity		55mm
True RMS	AC Voltage	√
LCD Backlight		√
Diode		√
MAX/MIN		√
Inrush Current	AC Current	√
Data Hold		√
Duty Cycle	0.1%~99.9%	√
Auto Power Off		√
Continuity Buzzer		√
Low Battery Indication		√
Full Icon Display		√
Input Impedance for DCV	≥10MΩ	√
General Characteristics
Power	9V Batteries (6F22)
LCD Size	47mm X 30mm
Product Color	Red and grey
Product Net Weight	533g
Product Size	286mm X 105mm X 45mm
Standard Accessories	Batteries, Test Lead, Tool Box, Point Contact Temperature Probe
Standard Individual Packing	Gift Box, Carrying Bag, English Manual
Standard Quantity Per Carton	20pcs
Standard Carton Measurement	600mm X 370mm X 474mm
Standard Carton Gross Weight	28.3kg
