Features
1. 10 sets of data storage
2. High/Low output voltage warning
3. LCD backlight
4. Lightweight, portable
| Specifications | Range | |
| UT658B | UT658 | |
| Input voltage | 3V~9.0V | 3.0V~9.0V |
| Voltage resolution | 0.01V | √ |
| Voltage monitoring accuracy | ±(1%+5) | √ |
| Current monitor | 0A~3.5A | 0.0A~3.0A |
| Current monitoring accuracy | ±(1%+5) | √ |
| Current resolution | 0.01A | √ |
| Energy | 0~39999mAh | 0~9999mAh |
| Capacity data storage | 10 sets | 10 sets |
| Display | LCD backlight | √ |
| Over voltage indication | ＞5.3V, ＜4.7V | √ |
| Working temperature | -10℃~40℃ | √ |
| Storage temperature | -10℃~50℃ | √ |
| Relative humidity | <75% | √ |
| Certification | CE, FCC, RoHS | CE, RoHS |
| Cable length | 10cm | |
